In most cases even the battery shop owner can’t figure out the exact special features about tubular battery. One thing everybody knows is Tubular is better than normal battery, but in which way it is better? Have you ever wonder why you can’t find the right answer for this question. Don’t worry guys; Let me simply list out the specialties about tubular battery.
A tubular battery uses technology that seals the active material in polyester tubes called gauntlets, instead of posting it on the surface of the plate. As a result, there's no shedding or corrosion, ensuring long battery life. Owing to their toughness and durability, tubular batteries can operate at extreme temperatures, and are used in high cyclic applications involving frequent and prolonged power outages.
| Type | Nominal Capacity AT. 10hr,RATE (AH.) |
Overall Sizes +/- mm | Battery Weight | Electrobyte Vol.(approx.) (Lts.) |
||||
|---|---|---|---|---|---|---|---|---|
| Lenght(mm) | Width | Height | (approx.)+/- 5% (kg.) | |||||
| Overall | Bottom | (mm) | (mm) | Dry | Wet. | |||
| AV 20 | 20 | 256 | 256 | 172 | 246 | 7.3 | 13.6 | 5.3 |
| AV 40 | 40 | 305 | 305 | 172 | 248 | 14.4 | 20.7 | 5.3 |
| AV 60 | 60 | 411 | 393 | 173 | 260 | 20.1 | 28.8 | 7.3 |
| AV 80 | 80 | 513 | 485 | 212 | 256 | 25.9 | 39 | 10.5 |
| AV 100 | 100 | 419 | 490 | 275 | 261 | 31.9 | 50 | 14.3 |
| AV 120 | 120 | 519 | 490 | 275 | 261 | 36.9 | 53.2 | 13.5 |
| AV 135 | 135 | 519 | 490 | 275 | 261 | 38.0 | 56.5 | 14.0 |
| AV 150 | 150 | 510 | 460 | 285 | 320 | 48.1 | 66.5 | 15.3 |
| AV 180 | 180 | 510 | 460 | 285 | 320 | 56.6 | 73 | 16.0 |
| AV 200 | 200 | 510 | 460 | 285 | 320 | 58.5 | 75 | 17.2 |
